• Country
• United States of America (USA)

• Manufacturer / Brand
• Crosley Radio Corp.; Cincinnati (OH)

• Year
• 1933/1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 261311

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 58 58 57 2A5 80

• Main principle
• Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast (MW), Police, sometimes also early TV (75-200m).

• Power type and voltage
• Alternating Current supply (AC) / Either transformer: 60 cycles, 115V or 25-60 cycles, 115V or 50-60 cycles, 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Dual Fiver Lowboy Ch= 167 [Modern Console - Late Production] - Crosley Radio Corp.;

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 21 x 36.625 x 11.375 inch / 533 x 930 x 289 mm

• Notes

• The Crosley Dual Fiver Lowboy is an AC operated 5 tube BC and Police band receiver. This model is the late production model (Crosley calls the late production version "Series 2") and uses the 2A5 output tube along with other passive component differences. The component differences are noted in the Riders schematics (Page 4-10).

  Model	Output Tube	Crosley Service Bulletin
  Dual Fiver (Early Production)	42	No. 67
  Dual Fiver (Late Production)	2A5	No. 72

  NOTE: The Schematics show the tube socket numbers, not the tube types!

• External source of data
• Crosley Brochure - Season 1933/34

• Source of data
• Pre-War Consoles

• Literature/Schematics (1)
• Rider's Perpetual, Volume 4 = ca. 1934 and before (Riders 4-9, 4-10)

• Literature/Schematics (2)
• - - Manufacturers Literature (Crosley Service Bulletin No. 72)

• Literature/Schematics (3)
• Crosley Radio Service Manual: 1943 Sets and Earlier (Page 203)

• Literature/Schematics (4)
• Beitman Radio Diagrams, Vol. 01, 1926-1938 (Page 40)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
