For model L330, Bogen, David Co., Inc.; New York (NY):
Picture from service manual.

Country:  United States of America (USA)
Manufacturer / Brand:  Bogen, David Co., Inc.; New York (NY)
Year: 1958 ? Category: Audio Amplifier or -mixer
Valves / Tubes 9: 12AX7 12AX7 6AV6 6U8 6AV5GA 6AV5GA 6CG7 5Y3GT 5Y3GT
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: L330 - Bogen, David Co., Inc.; New
Material Metal case
Shape Book-shelf unit.
Notes

David Bogen model L330 is an AC operated 6 channel 30 watt amplifier.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 392 Folder 8 dated 3-58)

Model page created by Dirk Taekels. See "Data change" for further contributors.
