PT/M; Decca, London (ID = 1251313) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Decca, London
alternative name

Decca Gramophone || Decca Radio
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6P8G 6U7G 6R7G 6V6G 5Z4G
Main principle Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: PT/M - Decca, London
Shape Tablemodel, with any shape - general.
Notes Push buttons for six pre-set radio stations. No manual tuning. Some early production sets have an IF of 125 kHz. The chassis is similar to that in the Brunswick 39/EH table radiogram.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (390)

Model page created by Howard Craven. See "Data change" for further contributors.
