TPW70 blue/cream

TPW70; Decca, London (ID = 1326711) Radio

TPW70; Decca, London (ID = 1326713) Radio
TPW70; Decca, London (ID = 2542555) Radio TPW70; Decca, London (ID = 1916197) Radio
TPW70; Decca, London (ID = 1916199) Radio TPW70; Decca, London (ID = 1916204) Radio
TPW70; Decca, London (ID = 1916205) Radio TPW70; Decca, London (ID = 1916208) Radio
Use red slider bar for more.
TPW70; Decca, London (ID = 2542555) Radio
Decca, London: TPW70 [Radio] ID = 2542555 1141x1060
Select picture or schematic to display from thumbnails on the right and click for download.
For model TPW70 blue/cream, Decca, London:
Gerät liegt im “Ye Olde Hurdy-Gurdy Museum of Vintage Radio“

Country:  Great Britain (UK)
Manufacturer / Brand:  Decca, London
alternative name

Decca Gramophone || Decca Radio
Year: 1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: OC44 OC45 OC45 OC81D OC81 OC81
Main principle Superheterodyne (common); ZF/IF 472 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2x6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TPW70 [blue/cream] - Decca, London
Material Modern plastics (no Bakelite or Catalin)
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Notes

Wall-mounted circular set 10" dia., 2.5" deep. Also in red/cream.

Source of data Radio! Radio!
Literature/Schematics (1) Trader sheet 1541

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
