Canopus Ch=10D591

Canopus Ch=10D591; De Forest DeForest (ID = 1065789) Radio

Canopus Ch=10D591; De Forest DeForest (ID = 2241862) Radio

Canopus Ch=10D591; De Forest DeForest (ID = 2241863) Radio

Canopus Ch=10D591; De Forest DeForest (ID = 2241864) Radio
Use red slider bar for more.
Canopus Ch=10D591; De Forest DeForest (ID = 1065789) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 20J8M 12K7M 12B6M 50C6G 50Y6G
Main principle Super-Heterodyne (Super in general); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Canopus Ch=10D591 - De Forest DeForest Crosley
Notes This model has a 6-pushbutton tuning system. This set is electrically identical to the Rogers 15/55A and the Majestic 4155A.
Circuit diagram reference Radio College of Canada
Mentioned in RCC Rogers-Majestic section, pages 85, 84 & Cross-Reference

Model page created by Robin Roeckers. See "Data change" for further contributors.
