De Forest DeForest: Electra Ch= 6D632 [Radio] ID = 2388698 360x540
Select picture or schematic to display from thumbnails on the right and click for download.
For model Electra Ch= 6D632, De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto:
This picture uploaded with permission from Terence Hayes from Ontario, Canada

Country:  Canada
Manufacturer / Brand:  De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6K7M 6A7M 6K7M 75M 6F6M 80
Main principle Superhet with RF-stage; ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Electra Ch= 6D632 - De Forest DeForest Crosley
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Notes BC: 530 - 1700 MC; SW1: 1.7 - 5.7 MC; SW3: 5.7 - 18.5. Rogers 11-60, 11-66, 11-68, Majestic Rodney, Renown, Hood and De Forest Mars are electronically identical to this set.
Price in first year of sale 79.95 $
External source of data Folder for season 1936/37.
Circuit diagram reference Radio College of Canada
Mentioned in RCC Rogers-Majestic section page 18, 18a & Cross-Reference
