Strauss Ch= 8D821

Strauss Ch= 8D821; De Forest DeForest (ID = 2240127) Radio

Strauss Ch= 8D821; De Forest DeForest (ID = 2240128) Radio

Strauss Ch= 8D821; De Forest DeForest (ID = 2240129) Radio

Strauss Ch= 8D821; De Forest DeForest (ID = 2240130) Radio
Strauss Ch= 8D821; De Forest DeForest (ID = 1108868) Radio
Use red slider bar for more.
Strauss Ch= 8D821; De Forest DeForest (ID = 1108868) Radio
De Forest DeForest: Strauss Ch= 8D821 [Radio] ID = 1108868 933x660
Select picture or schematic to display from thumbnails on the right and click for download.
For model Strauss Ch= 8D821, De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto:
Scanned from the DeForest Crosley flier 1939 (CDN).

Country:  Canada
Manufacturer / Brand:  De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6K7M 6J8M 6K7M 75M 6X6 41M 2X3 2X3
Main principle Superhet with RF-stage; ZF/IF 456 kHz; 1 AF stage(s)
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Strauss Ch= 8D821 - De Forest DeForest Crosley
Material Wooden case
Shape Console with any shape - in general
Notes The 6X6 is a tuning indicator tube. This set is electrically identical to the Rogers 13/86 and the Majestic 886 models. Same as THE PRYOR, except NOT the "Finger-Tip" Control feature.
Price in first year of sale 119.95 $
Circuit diagram reference Radio College of Canada
Mentioned in RCC Rogers-Majestic section page 46 & Cross-Reference

Model page created by Robin Roeckers. See "Data change" for further contributors.



All listed radios etc. from De Forest (DeForest) Crosley Radio, Consolidated Industries; Toronto
Here you find 250 models, 105 with images and 169 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
