Nivico Transistor Television 4T-50UHF

Delmonico; Long Island City (NY)

  • Year
  • 1966 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 202163

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 29
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Powered by external power supply or a main unit. / 12, 9 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 3 inch = 7.6 cm
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Nivico Transistor Television 4T-50UHF - Delmonico; Long Island City NY
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 8.4 x 4.4 x 8.75 inch / 213 x 112 x 222 mm
  • Notes
  • Delmonico Transistor Television 4T-50UHF;
    4.5" 55° CRT b/w TV with US standard VHF turret & UHF dial tuner, earphone & ext. antenna jacks, 5/3.5 W power consumption,

    Made in Japan by JVC

  • Net weight (2.2 lb = 1 kg)
  • 8.5 lb (8 lb 8 oz) / 3.859 kg
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
