• Country
• Japan

• Manufacturer / Brand
• Denon (Marke / brand)

• Year
• 1985/1986

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 144731

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Record Player (not changer); Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 120; 120/220/240; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: Micro Processor Controlled Fully Automatic Turntable System DP-37F - Denon Marke / brand

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 434 x 145 x 410 mm / 17.1 x 5.7 x 16.1 inch

• Notes
• Vollautomatischer, direktgetriebener Plattenspieler mit "Dynamic Servo Tracer"-Tonarm. 2 Geschwindigkeiten 33 und 45 UpM.
  Plattenteller Alu-Druckguss 300mm.
  MC-Tonabnehmer, Systemträger PCL-30, Nadel DL-110.

• Net weight (2.2 lb = 1 kg)
• 7.5 kg / 16 lb 8.3 oz (16.52 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
