Studio Quartz Direct Drive Turntable DP-2500

Denon (Marke / brand)

Data
Forum
Pictures
Collections

  • Year
  • 1978
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 247514

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Record Player (not changer); Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 100 or 120 or 220-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Studio Quartz Direct Drive Turntable DP-2500 - Denon Marke / brand
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 490 x 165 x 400 mm / 19.3 x 6.5 x 15.7 inch
  • Notes

  • A direct drive two speed (33, 45rpm) stereo hi-fi manual turntable complete with tonearm with anti-skate.  AC servo control with quartz reference. 300mm 1.5 kg cast aluminium alloy platter. Power consumption 17 watts. Walnut plinth.

    Denon direktgetriebener Plattenspieler Modell Studio DP-2500.
    2 Geschwindigkeiten 33 & 45 U/min
    Plattenteller: Alu-Legierung Spritzguss 300mm, 1,5 kg
    Leistungsaufnahme 17 Watt.
    Konsole: Nussbaum.


  • Net weight (2.2 lb = 1 kg)
  • 12 kg / 26 lb 6.9 oz (26.432 lb)
  • Mentioned in
  • -- Original prospect or advert (Denon 1978/79 Hi-Fi Programm)
  • Literature/Schematics (1)
  • Funkschau (21/1978, S. 1015)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
