Amator Stereo DSS-101

Amator Stereo DSS-101; Unitra DIORA - (ID = 318426) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 318429) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413837) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413838) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413839) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413840) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413841) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413842) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413843) Radio

Amator Stereo DSS-101; Unitra DIORA - (ID = 1413844) Radio
Amator Stereo DSS-101; Unitra DIORA - (ID = 257039) Radio Amator Stereo DSS-101; Unitra DIORA - (ID = 257041) Radio
Amator Stereo DSS-101; Unitra DIORA - (ID = 1130615) Radio Amator Stereo DSS-101; Unitra DIORA - (ID = 1130616) Radio
Amator Stereo DSS-101; Unitra DIORA - (ID = 1796140) Radio Amator Stereo DSS-101; Unitra DIORA - (ID = 1796141) Radio
Amator Stereo DSS-101; Unitra DIORA - (ID = 2155946) Radio Amator Stereo DSS-101; Unitra DIORA - (ID = 2155947) Radio
Amator Stereo DSS-101; Unitra DIORA - (ID = 2155948) Radio Amator Stereo DSS-101; Unitra DIORA - (ID = 2155949) Radio
Use red slider bar for more.
Amator Stereo DSS-101; Unitra DIORA - (ID = 257039) Radio
Unitra DIORA -: Amator Stereo DSS-101 [Radio] ID = 257039 933x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amator Stereo DSS-101, Unitra DIORA - Radiowerk Dzierzoniow,:
Serien Nr.: 968024

Country:  Poland
Manufacturer / Brand:  Unitra DIORA - Radiowerk Dzierzoniow,
Year: 1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12: BF195 BF195 BF195 BF194 BF194 BF196 BC149 BC149 2N3055 BC211 BC147 BC211
Main principle Superheterodyne (common); ZF/IF 465/10700 kHz
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 8 W (undistorted)
from Radiomuseum.org Model: Amator Stereo DSS-101 - Unitra DIORA - Radiowerk
Material Various materials
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 495 x 115 x 240 mm / 19.5 x 4.5 x 9.4 inch
Notes

Der Empfänger Amator Stereo enthält 5 ICs. Zur Ausstattung gehören Anschlüsse für TA/ TB und 2x KW. Die Ausgangsleistung beträgt 2x 4 Watt.

Net weight (2.2 lb = 1 kg) 4.7 kg / 10 lb 5.6 oz (10.352 lb)
Source of data - - Data from my own collection
Literature/Schematics (1) Kókai-Varsányi: Sztereó rádiók szervizkönyve, Budapest 1982.
Literature/Schematics (2) Importgeräte- CD Funkverlag B. Hein

Model page created by Jörg Kulbe. See "Data change" for further contributors.
