• Year
  • 1976
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 125491

 Technical Specifications

  • Number of Transistors
  • 13
  • Semiconductors
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 13,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch
  • Power out
  • 0.5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Kurier 3000 - DNT Drahtlose
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 130 x 40 x 195 mm / 5.1 x 1.6 x 7.7 inch
  • Notes
  • 12-Kanal-AM-Mobilfunkgerät für das 27-MHz-Band. 0,5 Watt HF-Ausgangsleistung. Instrumentenanzeige.

    FTZ Nr. PR27-238M /76

    Kanalwähler ist beleuchtet und mit Buchstaben (A - L) versehen.

  • Net weight (2.2 lb = 1 kg)
  • 0.9 kg / 1 lb 15.7 oz (1.982 lb)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
