For model Neutrodyne, Dobbie A.W. and Company (Dobbico); Adelaide, South Australia:
A.W.Dobbie TRF Neutrodyne radio front view

Country:  Australia
Manufacturer / Brand:  Dobbie A.W. and Company (Dobbico); Adelaide, South Australia
Year: 1925 ? Category: Radio module pre 1926 (not a part, not a key)
Valves / Tubes 5:
Main principle TRF without regeneration; 2 AF stage(s); Neutrodyne
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Is a battery or storage battery
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Neutrodyne - Dobbie A.W. and Company
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 650 x 345 x 300 mm / 25.6 x 13.6 x 11.8 inch
Notes

This is a King Manufacturing USA  Neutrodyne TRF kit imported assembled and wired up by A.W.Dobbie in South Australia about 1925.

Model page created by Lindsay Shepherd. See "Data change" for further contributors.
