D2205

D2205; Ducretet -Thomson; (ID = 81529) Radio

D2205; Ducretet -Thomson; (ID = 81531) Radio

D2205; Ducretet -Thomson; (ID = 81533) Radio
D2205; Ducretet -Thomson; (ID = 2381571) Radio D2205; Ducretet -Thomson; (ID = 2381575) Radio
D2205; Ducretet -Thomson; (ID = 2381574) Radio D2205; Ducretet -Thomson; (ID = 245454) Radio
D2205; Ducretet -Thomson; (ID = 245457) Radio D2205; Ducretet -Thomson; (ID = 64813) Radio
D2205; Ducretet -Thomson; (ID = 245455) Radio D2205; Ducretet -Thomson; (ID = 245456) Radio
D2205; Ducretet -Thomson; (ID = 245458) Radio D2205; Ducretet -Thomson; (ID = 1054542) Radio
Use red slider bar for more.
D2205; Ducretet -Thomson; (ID = 2381571) Radio
Ducretet -Thomson;: D2205 [Radio] ID = 2381571 1400x934
Select picture or schematic to display from thumbnails on the right and click for download.
For model D2205, Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name

SED
Year: 1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6E8 6K7 or 6M7 6Q7 or 6H8 25L6 25Z6G
Main principle Superheterodyne (common); ZF/IF 472 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12.5 cm = 4.9 inch
Power out
from Radiomuseum.org Model: D2205 - Ducretet -Thomson; avant:
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 290 x 200 x 180 mm / 11.4 x 7.9 x 7.1 inch
Notes Variante du schéma avec utilisation d-une 6Q7, en détectrice at préamplificatrice B.F.
External source of data Serge Laffont/Martin Renoth


All listed radios etc. from Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
Here you find 632 models, 484 with images and 277 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
