Poste à 5 lampes forme piano A5

Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

Data
Forum
Pictures
Collections

  • Year
  • 1924
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 199139
    • alternative name: SED

 Technical Specifications

  • Number of Tubes
  • 5
  • Valves / Tubes
  • Main principle
  • TRF (Tuned-Radio-Frequency but use of regeneration unknown)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage and/or dry batteries / 4 & 80 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Poste à 5 lampes forme piano A5 - Ducretet -Thomson; avant:
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 260 x 330 x 220 mm / 10.2 x 13 x 8.7 inch
  • Notes

  • Ducretet Piano A5 (5 Lampes);
    200 - 4000 m = 75 kHz - 1.500 kHz.

  • Net weight (2.2 lb = 1 kg)
  • 4.750 kg / 10 lb 7.4 oz (10.463 lb)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
