• Year
  • 1928 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 111383
    • alternative name: SED

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); Reaction
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage and/or dry batteries / 4 & 80 or 120 & -3 to -12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radiomodulateur RM6 [cadre incurvé] - Ducretet -Thomson; avant:
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 410 x 265 x 240 mm / 16.1 x 10.4 x 9.4 inch
  • Notes
  • Le récepteur Radiomodulateur RM6 comporte 6 lampes : 1 bigrille, 2 MF, 1 détectrice, et 2 BF. Audition sur 4 lampes (avec casque) ou sur 4 ou 5 lampes (en haut-parleur). Réception avec antenne cadre ou simple antenne extérieure.

    Circuits fréquence intermédiaire à réaction. L'appareil a besoin d'une batterie de polarisation externe (C-Battery) en cas d'utilisation des lampes R56 ou B406 sur l'étage BF.

    Coffret en noyer verni. Face en aluminium émaillé noir., bordure de cadre incurvée. Prix sans lampes.

  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Price in first year of sale
  • 1,950.00 FRF
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by John Koster. See "Data change" for further contributors.
