Phonomodula PM6 coffret arrondi

Phonomodula PM6; Ducretet -Thomson; (ID = 1715040) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715041) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715042) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715043) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715044) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715045) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715046) Radio

Phonomodula PM6; Ducretet -Thomson; (ID = 1715047) Radio
Phonomodula PM6; Ducretet -Thomson; (ID = 146398) Radio Phonomodula PM6; Ducretet -Thomson; (ID = 146400) Radio
Phonomodula PM6; Ducretet -Thomson; (ID = 1546735) Radio Phonomodula PM6; Ducretet -Thomson; (ID = 1546736) Radio
Phonomodula PM6; Ducretet -Thomson; (ID = 1546738) Radio Phonomodula PM6; Ducretet -Thomson; (ID = 1715048) Radio
Phonomodula PM6; Ducretet -Thomson; (ID = 2020442) Radio Phonomodula PM6; Ducretet -Thomson; (ID = 2020443) Radio
Phonomodula PM6; Ducretet -Thomson; (ID = 2020446) Radio
Use red slider bar for more.
Phonomodula PM6; Ducretet -Thomson; (ID = 146398) Radio
Ducretet -Thomson;: Phonomodula PM6 [Radio] ID = 146398 846x598
Select picture or schematic to display from thumbnails on the right and click for download.
For model Phonomodula PM6 coffret arrondi, Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name

SED
Year: 1929 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: R43M R78 or DZ2222-Métal R78 or DZ2222-Métal R75 or DZ1508-Métal R85 or DY604 R77 or DX502 A409
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 4 & 80 & 4.5 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Phonomodula PM6 [coffret arrondi] - Ducretet -Thomson; avant:
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 400 x 290 x 225 mm / 15.7 x 11.4 x 8.9 inch
Notes

Gamme de réception: de 25 m à 2000 m, sur cadre (fourni avec l'appareil, commutateur PO-MO-GO) ou sur antenne (seul fil de 20 m, avec bobines rouges).

Alimentation: pile(s) par tension plaque de 80 à 160 volts; accumulateur par chauffage à 4 volts; pile de polarisation de grille à -4,5 volts ou -15 et -26 volts.

Jeu des lampes:

  • Bigrille: R43M ou brigrille spéciale OC pour ondes courtes
  • HF1 et HF2: R78 ou DZ2222
  • Détectrice: R75 ou R76 ou DZ1508 ou A409 ou Fotos C9
  • BF1: R85 ou DY604 ou B409 ou Fotos D9
  • BF2: R77 ou DX502 ou B405
  • Lampe complémentaire spécial PU: A409

Ébénisterie en acajou verni.

Prix nu, sans lampes. Bobines rouges pour réception sur antenne, la pièce: 30 Fr.

Price in first year of sale 1'075.00 FRF
External source of data Christian ADAM
Mentioned in - - Manufacturers Literature (Télégraphie et Télephonie sans fil, No. 441, 1929)
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 670)

Model page created by Ernst Erb. See "Data change" for further contributors.
