Colony Ch= 120600A Ch=120601A

DuMont Labs, Allen B., Inc.

  • Year
  • 1959 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 140265
    • alternative name: Dumont Television & Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • from Radiomuseum.org
  • Model: Colony Ch= 120600A Ch=120601A - DuMont Labs, Allen B., Inc.
  • Notes
  • With picture tube 21CBP4A. Channels 2 thru 13 VHF, 14 thru 83 UHF: Sams photofact set 502 folder 1 date 10-60 features the Dumont models Benton, Biarritz, Bradford, Colony, DeVille, Hampton, Lauderdale, Marquette, Montclair, Norwood, Oxford and Sussex with chassis 120600A and chassis 120601A as the same schematic.
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
