• Year
  • 1954
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 157512
    • alternative name: Dumont Television & Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line (AC, UC or DC not known) / Either 117 or 220 Volt
  • Loudspeaker
  • Permanent or electro-dynamic (moving coil), system not known yet.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: RA-306 - DuMont Labs, Allen B., Inc.
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Dumont RA-306;
    B/W TV with US FCC standard VHF tuner.

    This model was also sold in Italy with a modified power supply with only a 5U4G rectifier and a different power transformer to operate with the 220V ac mains.

  • Circuit diagram reference
  • Photofact Folder, Howard W. SAMS
  • Literature/Schematics (1)
  • Folder 6 Set 241, June 1954
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
