For model Dynakit Mark II (2), Dyna Co. (Dynaco); Philadelphia PA:
aus ebay, Verkäufer 418iaka

Country:  United States of America (USA)
Manufacturer / Brand:  Dyna Co. (Dynaco); Philadelphia PA
Year: 1955 ? Category: Audio Amplifier or -mixer
Valves / Tubes 4: 6AN8 EL34 EL34 5U4G
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - This model requires external speaker(s).
Power out 50 W (unknown quality)
from Radiomuseum.org Model: Dynakit Mark II - Dyna Co. Dynaco; Philadelphia
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 9 x 6.75 x 9 inch / 229 x 171 x 229 mm
Notes Monoblock; with power supply for PreAmp.
Net weight (2.2 lb = 1 kg) 27 lb (27 lb 0 oz) / 12.258 kg
Price in first year of sale 60.00 $

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
