• Country
• Germany

• Manufacturer / Brand
• Dynacord (W. Pinternagel); Straubing

• Year
• 1987

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 324457

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 25

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Loudspeaker + integr.Amplifier

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 10 inch = 25.4 cm

• Power out
• 300 W (max.)

• Material
• Various materials

• from Radiomuseum.org
• Model: Reference 3002 - Dynacord W. Pinternagel;

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 665 x 490 x 370 mm / 26.2 x 19.3 x 14.6 inch

• Notes

• Bauweise:       zweigeteilter Basscombo,
  Leistung:         300W an 4 Ohm
  Lautsprecher:  2x (4x) 10" Foster

  Ausstattung:    Gain, Volume, Voicing Filter, Compressor,
                          11-Band-Graphic-EQ,
                          Biamp-Volume und Frequenz, Master-Volume

  Anschlüsse:     Input Lo/Hi, Studio Output (XLR),
                          zwei Einschleifwege, Subwoofer Out,
                          zwei Speaker Outputs

  Preis:               DM 2740,-- (Verstärker + Zusatzbox 2x 10" LS)



• Net weight (2.2 lb = 1 kg)
• 38.5 kg / 84 lb 12.8 oz (84.802 lb)

• Price in first year of sale
• 2,740.00 DM

• Author
• Model page created by Hannes Gerber. See "Data change" for further contributors.
