• Country
• Hungary

• Manufacturer / Brand
• Echo, Vörös Rezső okl. gépészmérnök Rádiólaboratóriuma; Budapest

• Year
• 1939

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124001

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 EBF2 EF6 EL3 EM4 EZ2

• Main principle
• Superheterodyne (common); ZF/IF 473 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• from Radiomuseum.org
• Model: Luxusszuper 400V - Echo, Vörös Rezső okl. gépészm

• Notes

• Speaker: Orion 8006A 5W

• Mentioned in
• Rádió Technika 1940.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
