For model 870 (S870), Eddystone, Birmingham:
eigenes Gerät

Country:  Great Britain (UK)
Manufacturer / Brand:  Eddystone, Birmingham
alternative name

Stratton & Co.Ltd.; Birmingham
Year: 1956–1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 19AQ5 35W4
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 210; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 870 - Eddystone, Birmingham
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 279 x 162 x 208 mm / 11 x 6.4 x 8.2 inch
Notes Broadcast general coverage receiver, covers 150 kHz - 18 MHz in four bands (150-380 kHz; 540-1500 kHz; 1,95-6,3 MHz, 5,9-18 MHz), AM only.
Mainly used as shipboard / cabin receiver for passengers on ocean liners.
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 34.00 GBP
Source of data Shortwave Receivers - Past & Present (3rd ed.)
Mentioned in Eddystone User Group: Quick Reference Guide

Model page created by Martin Bösch. See "Data change" for further contributors.
