990S
Use red slider bar for more.
Eddystone,: 990S [Commercial Re] ID = 1183306 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Stratton & Co.Ltd.; Birmingham | ||||
|---|---|---|---|---|---|
| Year: 1968–1978 | Category: Commercial Receiver (may include amateur bands) | ||||
| Semiconductors (the count is only for transistors) | 42: |
| Main principle | Superhet with RF-stage; ZF/IF 36500 kHz |
|---|---|
| Wave bands | Wave Bands given in the notes. |
| Details | |
| Power type and voltage | Line / Batteries (any type) / 100-130; 200-260 / 12 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | |
| from Radiomuseum.org | Model: 990S - Eddystone, Birmingham |
| Material | Metal case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 502 x 172 x 378 mm / 19.8 x 6.8 x 14.9 inch |
| Notes | UHF communication receiver covering 230 - 870 MHz in two bands, AM, FM. S-Meter, integrated crystal calibrator. |
| Source of data | -- Collector info (Sammler) |
Model page created by Martin Bösch. See "Data change" for further contributors.
