Phonograph Standard B
Edison, Thomas A., North American Phonograph / National Phonograph; Orange, NJ
- Country
- United States of America (USA)
- Manufacturer / Brand
- Edison, Thomas A., North American Phonograph / National Phonograph; Orange, NJ
- Year
- 1905
- Category
- Talking machine - Mechanical Gramophone/Phonograph
- Radiomuseum.org ID
- 130174
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Solar- and/or muscle driven, also addl. power jack possible
- Loudspeaker
- Horn
- Material
- Wooden case
- from Radiomuseum.org
- Model: Phonograph Standard B - Edison, Thomas A., North
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 13 x 11.75 x 9.5 inch / 330 x 298 x 241 mm
- Notes
- For 2 min. cylinders only. Internal thread end wind handle(crank).
- Literature/Schematics (1)
- Brian Jewell: Veteran Talking Machines.
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
