• Country
• United States of America (USA)

• Manufacturer / Brand
• Educational Electronics Company; Chicago (IL)

• Year
• 1955 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 290418

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors

• Main principle
• Crystal or Solid State Detector with Amplifer; 1 AF stage(s); Crystal-detection 1 circuit (no tubes)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 2 x 1.5 Volt

• Loudspeaker
• - Is a Headphone or Earphone

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 4 in 1 Transistor Radio Kit 130 - Educational Electronics

• Dimensions (WHD)
• 12 x 8 x 4 inch / 305 x 203 x 102 mm

• Notes

• Set number 130 of a series.

• Net weight (2.2 lb = 1 kg)
• 1 lb (1 lb 0 oz) / 0.454 kg

• Literature/Schematics (1)
• -- Schematic

• Literature/Schematics (2)
• -- Original-techn. papers.

• Author
• Model page created by Steve McInnis. See "Data change" for further contributors.
