• Country
• Germany

• Manufacturer / Brand
• EDUTEC ("Marke" / "brand")

• Year
• 1995 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 345643

• • Brand: Eduscho

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 50 Hz, 230 & backup for clock 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Alarm Clock Radio - Uhrenradio unbekannt - EDUTEC "Marke" / "brand"

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Dimensions (WHD)
• 195 x 75 x 80 mm / 7.7 x 3 x 3.1 inch

• Notes

• Timer backup battery: 9 V.

• Net weight (2.2 lb = 1 kg)
• 0.492 kg / 1 lb 1.3 oz (1.084 lb)

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
