For model AC74 brown, Ekco, E.K.Cole Ltd.; Southend-on-Sea

Country:  Great Britain (UK)
Manufacturer / Brand:  Ekco, E.K.Cole Ltd.; Southend-on-Sea
Year: 1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: SP4 VP4 TDD4 Pen4V IW3
Main principle Super-Heterodyne (Super in general); ZF/IF 110 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: AC74 [brown] - Ekco, E.K.Cole Ltd.; Southend-
Material Bakelite case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 15 x 18 x 10 inch / 381 x 457 x 254 mm
Notes Shadow tuning indicator.
Collectors' prices
Source of data Radio! Radio!

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
