Round Ekco AC76 brown

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 210786) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1028528) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1028529) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1028530) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1254101) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1254102) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1254103) Radio

Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1254104) Radio
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1148679) Radio Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 201031) Radio
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 201032) Radio Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 201033) Radio
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 201034) Radio Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1388485) Radio
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1388488) Radio Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1388491) Radio
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1388493) Radio Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1388495) Radio
Use red slider bar for more.
Round Ekco AC76; Ekco, E.K.Cole Ltd.; (ID = 1148679) Radio
Ekco, E.K.Cole Ltd.;: Round Ekco AC76 [Radio] ID = 1148679 933x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Round Ekco AC76 brown, Ekco, E.K.Cole Ltd.; Southend-on-Sea

Country:  Great Britain (UK)
Manufacturer / Brand:  Ekco, E.K.Cole Ltd.; Southend-on-Sea
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: FC4 AC/VP1 V914 or 2D4A AC2/Pen UU3 or IW3
Main principle Super-Heterodyne (Super in general); ZF/IF 130 kHz; 2 AF stage(s); Reflex
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20.5 cm = 8.1 inch
Power out
from Radiomuseum.org Model: Round Ekco AC76 [brown] - Ekco, E.K.Cole Ltd.; Southend-
Material Bakelite case
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 400 x 410 x 200 mm / 15.7 x 16.1 x 7.9 inch
Notes AC76 was for AC-operation only, AD76 for AC/DC-use. Both versions were available in black or in brown (walnut) Bakelite. Matching wooden stand (26,5" high) optional.
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Price in first year of sale 12.00 GBP
Collectors' prices
Source of data Radio! Radio!
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (108)
Literature/Schematics (2) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (671)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from Ekco, E.K.Cole Ltd.; Southend-on-Sea
Here you find 397 models, 271 with images and 253 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Ekco, E.K.Cole Ltd.;: Round Ekco AC76
Threads: 2 | Posts: 4
Hits: 2211     Replies: 2
ekco: AC76 (AC 76); Round Ekco
Reiner Scholz
07.Jul.08
  1 Hello, is anybody out there, who knows the original colour of the speaker cloth of EKCO AC76 -black-?
Maitiu Standun
07.Jul.08
  2 hello reiner, ben dijkman[A*T]home.nl can supply and advise you re speaker cloth for your ecko, sorry about the blank reply, regards maitiu.
Reiner Scholz
07.Jul.08
  3 Hello Maitiu, thanks a lot for this advice.

Hits: 1622     Replies: 0
ekco: AC76 (AC 76); Round Ekco, schwarz
Reiner Scholz
07.Jul.08
  1 Ich suche für die Restauration meines AC76 - schwarz- die Originalfarbe (im Neuzustand) des Lautsprechertuchs.
Ist sie hell - beige, blass - gold oder hell - braun gewesen?

Ekco, E.K.Cole Ltd.;: Round Ekco AC76
