• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ekco, E.K.Cole Ltd.; Southend-on-Sea

• Year
• 1956

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 97519

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• PCC84 or 30L1 PCF80 or 30C1 EF85 30F5 30FL1 6/30L2 30FL1 6D2 6/30L2 30P4 U25 U191 30F5 30F5 6D2 6D2 30P12 30P12 30PL1 CRM171

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 200 - 250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: T293 - Ekco, E.K.Cole Ltd.; Southend-

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes
• Table TV receiver with a 17 inch 405 line b/w CRT and GB Band I/III TV and Band II radio VHF tuner. Optional "armchair" remote control unit.

• Price in first year of sale
• 88.00 GBP

• Source of data
• -- Collector info (Sammler)

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1278/T115)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
