• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1968–1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 117947

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• BCY51 or. BC148 BCY51 or. BC148 AC175 or. AC187 AC117 or. AC188 BZY87 B30C1400/700

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch

• Power out
• 3 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 161TV - Elac Electroacustic GmbH; Kiel

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 410 x 170 x 256 mm / 16.1 x 6.7 x 10.1 inch

• Notes
• Phono-Chassis = 161.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Price in first year of sale
• 275.00 DM

• Source of data
• Handbuch VDRG 1968/1969

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
