Miracord 90

Miracord 90; Elac Electroacustic (ID = 2048215) R-Player Miracord 90; Elac Electroacustic (ID = 2130042) R-Player
Miracord 90; Elac Electroacustic (ID = 952441) R-Player Miracord 90; Elac Electroacustic (ID = 2048217) R-Player
Miracord 90; Elac Electroacustic (ID = 2048220) R-Player Miracord 90; Elac Electroacustic (ID = 2048221) R-Player
Miracord 90; Elac Electroacustic (ID = 2048222) R-Player Miracord 90; Elac Electroacustic (ID = 2048223) R-Player
Miracord 90; Elac Electroacustic (ID = 2130045) R-Player Miracord 90; Elac Electroacustic (ID = 2130046) R-Player
Use red slider bar for more.
Miracord 90; Elac Electroacustic (ID = 2048215) R-Player
Elac Electroacustic: Miracord 90 [R-Player] ID = 2048215 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Miracord 90, Elac Electroacustic GmbH; Kiel

Country:  Germany
Manufacturer / Brand:  Elac Electroacustic GmbH; Kiel
Year: 1959–1961 Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Miracord 90 - Elac Electroacustic GmbH; Kiel
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 329 x 271 x 200 mm / 13 x 10.7 x 7.9 inch
Notes

Drehzahl des Plattentellers: 16/33/45/78 UpM; Stereo-Kristallsystem, Frequenzbereich 30-15000 Hz.

ES gab zwei Varianten des Miracord 90 - eine ELAC-eigene und eine, die speziell für die Firma Braun für diverse Musikschränke (z.B. RS 10 W) produziert wurde. Die ELAC-Variante hatte eine weisse Skala für die Geschwindigkeitseinstellung und den Schriftzug "ELAC Miracord 90", die Braun-Variante eine metallfarbene Skala und einen Schriftzug "Electroacustic" neben der Start-Taste.

Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Price in first year of sale 164.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61 / Radiokatalog Band 2, Ernst Erb
