• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1955–1957

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 20112

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Miraphon 11 - Elac Electroacustic GmbH; Kiel

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 327 x 137 x 269 mm / 12.9 x 5.4 x 10.6 inch

• Notes

• Magnet-System; Frequenzbereich 20-20000 Hz.

  Tonabnehmer MST2

• Net weight (2.2 lb = 1 kg)
• 3.4 kg / 7 lb 7.8 oz (7.489 lb)

• Price in first year of sale
• 164.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1955/56 / Radiokatalog Band 2, Ernst Erb
