Miracord 5 PW5C
Elac Electroacustic GmbH; Kiel
- Country
- Germany
- Manufacturer / Brand
- Elac Electroacustic GmbH; Kiel
- Year
- 1957–1960
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 21592
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Miracord 5 PW5C - Elac Electroacustic GmbH; Kiel
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 329 x 271 x 190 mm / 13 x 10.7 x 7.5 inch
- Notes
-
4 Geschwindigkeiten 16/33/45/78 Upm; Kristall-System, Pausenwerk, Repetiereinrichtung.
Ausführungen:
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Price in first year of sale
- 184.00 DM
- External source of data
- Erb
- Source of data
- -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- HdB d.Rdf-& Ferns-GrH 1957/58 (und 1958/59)
- Literature/Schematics (2)
- HdB d.Rdf-& Ferns-GrH 1959/60
- Literature/Schematics (3)
- Handbuch RFP 1957 (und 1958/59)
