Tri-Tracer 700

Tri-Tracer 700; Nakamichi Co.; Tokyo (ID = 449547) R-Player Tri-Tracer 700; Nakamichi Co.; Tokyo (ID = 449550) R-Player
Tri-Tracer 700; Nakamichi Co.; Tokyo (ID = 349856) R-Player
Use red slider bar for more.
Tri-Tracer 700; Nakamichi Co.; Tokyo (ID = 449547) R-Player
Nakamichi Co.; Tokyo: Tri-Tracer 700 [R-Player] ID = 449547 920x571
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tri-Tracer 700, Nakamichi Co.; Tokyo:
By courtesy of Lauritz.com (Bild bearbeitet)

Country:  Japan
Manufacturer / Brand:  Nakamichi Co.; Tokyo
Year: 1974–1977 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 105:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 100; 117; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Tri-Tracer 700 - Nakamichi Co.; Tokyo
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 290 x 150 mm / 20.5 x 11.4 x 5.9 inch
Notes ICs: 8.
Viertelspur-Stereo, 3 Köpfe, relaisgesteuerte Laufwerksfunktionen, Zwei-Motoren-Antrieb, Feinregelung der Geschwindigkeit ± 6 %, Dolby.
Vertrieb in D über ELAC.
Gehäuseausführung in Nussbaum, Frontseite mattsilber/schwarz.
Net weight (2.2 lb = 1 kg) 12.7 kg / 27 lb 15.6 oz (27.974 lb)
External source of data Erb
Source of data Katalog RFP 1974 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch VDRG 1975/1976 (und 1976/77)
