• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1963

• Category
• Miscellaneous (Other, Various) - see notes

• Radiomuseum.org ID
• 320859

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo-Abtaster - Magnetsystem STS322 - Elac Electroacustic GmbH; Kiel

• Notes

• Prinzip: bewegter Magnet (MM). Frequenzbereich 20...20.000 Hz, Auflagekraft 1,5...3,0 p

• Net weight (2.2 lb = 1 kg)
• 0.110 kg / 0 lb 3.9 oz (0.242 lb)

• Mentioned in
• Funk-Technik (FT) (2/1963, S. 46 - 50 / Ausführliche Beschreibung, Daten (Neuvorstellung))

• Author
• Model page created by Oswald Bettendorf. See "Data change" for further contributors.
