Bearcat 101 BC-101

Country:  United States of America (USA)
Manufacturer / Brand:  Electra Co. / Corp. (Masco); Cumberland, IN
Brand

Bearcat
Year: 1970 ?? Category: Commercial Receiver (may include amateur bands)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Bearcat 101 BC-101 - Electra Co. / Corp. Masco;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 9 x 3.675 x 7.25 inch / 229 x 93 x 184 mm
Notes Bearcat 101, BC-101;
Programmable 16 channels scanner,
Coverage five bands:
30-50 MHz,
146-148 MHz,
148-174 MHz,
450-470 MHz,
470-512 MHz & 416-450 MHz government band,
scan rate is 20 channels per second, telescopic antenna or ext. coax in, 30 W power consumption, made in the USA.
Net weight (2.2 lb = 1 kg) 6.25 lb (6 lb 4 oz) / 2.838 kg
