• Year
  • 1950 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 306199

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 110-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Airline L-319 LCC62-417Z - Electrohome Dominion
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Notes
  • The Electrohome Airline model L-319 is a 6-tube console radio with tuning eye tube and built-in Webster 50 record changer. Covers standard broadcast and 6 to 17 MHz shortwave.

  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
