Apollo Circa 711

Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)

Data
Forum
Pictures
Collections

  • Year
  • 1970 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 184799

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Apollo Circa 711 - Electrohome Dominion
  • Shape
  • Console, Highboy (legs > 50 %).
  • Notes

  • Space Age Bubble Stereo Unit with Brushed Aluminum Tulip Pedestal.

    Electrohome model 711, code 400-203 indicates Changer BSR Mini Deluxe C114 and colors would be chrome, gold, red, blue and tangerine.

    You will find attached two Electrohome Data Sheets, one model 711, serial X appears to be an earlier version with similar information to the other, but less detail.

    Electrohome Data Sheets, model 711 code 400-203 has the color parts, the BSR changer number but there could be a mistake in listing one of the transistors.  The schematic parts list for the tuner shows a SE5000 for Q2,Q3,Q6,Q7, & Q8.  In past models that I have set up and the 711 serial X with the H-11 tuner, the number is SE500G, yet it is the same part number in both models 711.

  • Literature/Schematics (1)
  • - - Manufacturers Literature (Electrohome model 711, serial X 1L-372-01)
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Electrohome model 711, code 400-203 1L-548-01)
