FAE Xirico CH= 14882

FAE Xirico CH= 14882; Electromoc EE (ID = 1520767) Radio
FAE Xirico CH= 14882; Electromoc EE (ID = 1520010) Radio FAE Xirico CH= 14882; Electromoc EE (ID = 1520011) Radio
FAE Xirico CH= 14882; Electromoc EE (ID = 1520014) Radio FAE Xirico CH= 14882; Electromoc EE (ID = 1520016) Radio
FAE Xirico CH= 14882; Electromoc EE (ID = 1520017) Radio FAE Xirico CH= 14882; Electromoc EE (ID = 1520018) Radio
FAE Xirico CH= 14882; Electromoc EE (ID = 1520019) Radio FAE Xirico CH= 14882; Electromoc EE (ID = 1520020) Radio
FAE Xirico CH= 14882; Electromoc EE (ID = 1520021) Radio FAE Xirico CH= 14882; Electromoc EE (ID = 1520022) Radio
Use red slider bar for more.
FAE Xirico CH= 14882; Electromoc EE (ID = 1520010) Radio
Electromoc EE: FAE Xirico CH= 14882 [Radio] ID = 1520010 933x1202
Select picture or schematic to display from thumbnails on the right and click for download.
For model FAE Xirico CH= 14882, Electromoc EE (Empresa Estatal Electrónica Electrotecnia); Mozambique

Country:  Mozambique
Manufacturer / Brand:  Electromoc EE (Empresa Estatal Electrónica Electrotecnia); Mozambique
Year: 1980 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 3: SF225 SF225 SF225 GA101 GA101 GA101 A210E
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Batteries / addl. power jack / 4 x 1.5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 15.5 cm = 6.1 inch
Power out
from Radiomuseum.org Model: FAE Xirico CH= 14882 - Electromoc EE Empresa Estatal
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 185 x 280 x 80 mm / 7.3 x 11 x 3.1 inch
Notes

The FAE Xirico radio was assembled in the Popular Republic of Mozambique by Electromoc EE enterprise at its "FAE - Fabrica de Aparelhos Electronicos" manufacturing plant, during the early 80's. The project and components were supplied by Stern Radio in German Democratic Republic (Xirico looks like a Stern Contura 2500/250R radio from outside, but they only share the cabinet looks, because the pcb layout, the schematics and the radio bands are different).

Xirico is the name of a very common bird in Mozambique. This equipment was very popular and everybody wanted one. Due to its low price, it was sold in large quantities during the socialist revolutionary period.

Most of these radios were destroyed by the high moisture from tropical weather, bad handling, civil war and bad quality batteries. So just a few of them have survived.

The speaker size is 10,5 x 15,5 cm, with 8 Ohm impedance and 2 VA input power.



Net weight (2.2 lb = 1 kg) 1.380 kg / 3 lb 0.6 oz (3.04 lb)

Model page created by Jose Mesquita. See "Data change" for further contributors.
