For model Diamond Dot PD-C1C, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne:
From service manual cover.

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1963 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 2: 12FX8 12FR8
Semiconductors (the count is only for transistors) 3: 2N591 AC128 AC128 OA674 or. OA675
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Diamond Dot PD-C1C - Astor brand, Radio Corporation
Material Metal case
Shape Chassis only or for «building in»
Notes

This push-button hybrid car radio could be used on vehicles with either positive or negative chassis by the correct type of polarity change-over plug.  The OA675 was used on later production.  Provision for an external speaker is provided, in which case the internal speaker is disconnected.

Price in first year of sale 47.25 AUS £
Literature/Schematics (1) - - Manufacturers Literature (Diamond Dot Service Data, PD-C1C-1, 10/12/1963.)
Literature/Schematics (2) J.R. Publications Car Radio Service Handbook (Page A48a.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
