For model A320 Stereo, Elektrotechnik Eisenach, VEB, (Ostd.):
Abdeckung Balanceregler fehlt

Country:  Germany
Manufacturer / Brand:  Elektrotechnik Eisenach, VEB, (Ostd.)
Year: 1981 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 21:
Main principle Superheterodyne (common); ZF/IF 455/ 10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 8 W (unknown quality)
from Radiomuseum.org Model: A320 Stereo - Elektrotechnik Eisenach, VEB,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 52 x 150 mm / 7.1 x 2 x 5.9 inch
Notes Stereoautoradio mit Kassettenabspielgerät; UKW-Bereich 88-104 MHz, Klangtasten. FM-Schaltkreis A225, AM-Schaltkreis A244, Stereodecoder A290 und NF-Endstufe 2× A210E; Ausgangsleistung: 2× 2 W.
Das Kassettenteil hat eine Bandendabschaltung. Vorstellung auf der Leipziger Herbstmesse 1981.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 1'200.00 Mark
Mentioned in Sortimentskatalog Elektroakustik (DDR, 1984)

Model page created by Wolfgang Lill. See "Data change" for further contributors.
