UHF Festfrequenz-Konverter
Elektrotechnik Eisenach, VEB, (Ostd.)
- Country
- Germany
- Manufacturer / Brand
- Elektrotechnik Eisenach, VEB, (Ostd.)
- Year
- 1969 ?
- Category
- Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
- Radiomuseum.org ID
- 188280
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 2
- Main principle
- RF Converter/Adapter (not voltage converter)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: UHF Festfrequenz-Konverter - Elektrotechnik Eisenach, VEB,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 155 x 60 x 136 mm / 6.1 x 2.4 x 5.4 inch
- Notes
- Voreingestellter Umsetzer. Umsetzung eines Kanals im Band IV (Kanal 21-39)auf Kanal 3 im Band I .
- Net weight (2.2 lb = 1 kg)
- 0.460 kg / 1 lb 0.2 oz (1.013 lb)
- Price in first year of sale
- 130.00 Mark
- Author
- Model page created by Volker MARTIN. See "Data change" for further contributors.
