Univerzal Meter Ganzuniv-4

Univerzal Meter Ganzuniv-4; Elektromos (ID = 2109440) Equipment
Univerzal Meter Ganzuniv-4; Elektromos (ID = 859550) Equipment Univerzal Meter Ganzuniv-4; Elektromos (ID = 859551) Equipment
Univerzal Meter Ganzuniv-4; Elektromos (ID = 859589) Equipment Univerzal Meter Ganzuniv-4; Elektromos (ID = 859592) Equipment
Univerzal Meter Ganzuniv-4; Elektromos (ID = 860892) Equipment Univerzal Meter Ganzuniv-4; Elektromos (ID = 861802) Equipment
Use red slider bar for more.
Univerzal Meter Ganzuniv-4; Elektromos (ID = 859550) Equipment
Elektromos: Univerzal Meter Ganzuniv-4 [Equipment] ID = 859550 686x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Univerzal Meter Ganzuniv-4, Elektromos Készülékek és Mérőműszerek Gyára - EKM; Esztergom:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Elektromos Készülékek és Mérőműszerek Gyára - EKM; Esztergom
Year: 1980 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) BC168 BC168
Wave bands - without
Details
Power type and voltage Dry Batteries / 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Univerzal Meter Ganzuniv-4 - Elektromos Készülékek és Mérőm
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 205 x 128 x 100 mm / 8.1 x 5 x 3.9 inch
Notes The same as Goerz "Unigor 4n".
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data -- Original prospect or advert

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Elektromos Készülékek és Mérőműszerek Gyára - EKM; Esztergom
Here you find 221 models, 214 with images and 96 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Elektromos: Univerzal Meter Ganzuniv-4
Threads: 1 | Posts: 1
Hits: 578     Replies: 0
elektrom: Universal Meter Ganzuniv-4
John Sykes
09.Feb.18
  1

I've just uploaded information on another meter (Venture, Multimeter 4, UK) which is identical to the Unigor/Metrawatt 4n.  This Ganzuniv-4 model listing has the wrong schematic attached; it shows the voltage ranges progressing in a 3-6-12 sequence, whereas the meter photos show the scales as 10-30-100 etc., as is correct for a 4n meter.  Also the schematic around the resistance measurement /current generation area Tr1 Tr2 is different.

John
