Dual Beam Oscilloscope 1568/2 (TR-4655/2)
Use red slider bar for more.
EMG, Orion-EMG,: Dual Beam Oscilloscope 1568/2 [Equipment] ID = 969321 894x700
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1981–1988 ?? | Category: Service- or Lab Equipment | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
|---|
| Wave bands | - without |
|---|---|
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 220 Volt |
| Loudspeaker | - - No sound reproduction output. |
| Power out | |
| from Radiomuseum.org | Model: Dual Beam Oscilloscope 1568/2 - EMG, Orion-EMG, Elektronikus M |
| Material | Metal case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 333 x 145 x 390 mm / 13.1 x 5.7 x 15.4 inch |
| Notes | DC - 30 MHz, sensibility: 10 mV/div. Dual time base. |
| Net weight (2.2 lb = 1 kg) | 11 kg / 24 lb 3.7 oz (24.229 lb) |
| Source of data | -- Original prospect or advert |
| Literature/Schematics (1) | MTA Kölcsönmüszerek Jegyzéke, Bp.1991 |
