• Country
• Hungary

• Manufacturer / Brand
• EMG, Orion-EMG, Elektronikus Mérökészülélek Gyára; Budapest

• Year
• 1978 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 162951

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Transiscope-D 1566 / TR-4650 - EMG, Orion-EMG, Elektronikus M

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 200 x 255 x 385 mm / 7.9 x 10 x 15.2 inch

• Notes
• Screen: 6×8 cm. Vertical amplifier: DC..20 MHz, sensiblity:50 mV/cm-20 V/cm.In imp: 1 MOhm, 40 pF. Horizontal amplifier: DC..1MHz, sensiblity: 100 mV/cm - 1 V/cm.In imp: 1 MOhm, 50 pF. Dual Beam Oszcilloszkop

• Net weight (2.2 lb = 1 kg)
• 12.5 kg / 27 lb 8.5 oz (27.533 lb)

• Literature/Schematics (1)
• MTA Kölcsönmüszerek Jegyzéke, Bp.1983

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
