Matador T2A-505

Matador T2A-505; Elektronska (ID = 2233580) Radio Matador T2A-505; Elektronska (ID = 2233581) Radio
Matador T2A-505; Elektronska (ID = 2233582) Radio Matador T2A-505; Elektronska (ID = 2233583) Radio
Matador T2A-505; Elektronska (ID = 2490744) Radio Matador T2A-505; Elektronska (ID = 2490745) Radio
Use red slider bar for more.
Matador T2A-505; Elektronska (ID = 2233580) Radio
Elektronska: Matador T2A-505 [Radio] ID = 2233580 1400x1012
Select picture or schematic to display from thumbnails on the right and click for download.
For model Matador T2A-505, Elektronska Industrija (Ei); Niš:
from my collection

Country:  Yugoslavia
Manufacturer / Brand:  Elektronska Industrija (Ei); Niš
Brand

Ei
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 11:
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Matador T2A-505 - Elektronska Industrija Ei; Niš
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 213 x 120 x 54 mm / 8.4 x 4.7 x 2.1 inch
Notes

Frequency range:

AM 520 - 1600 kHz

FM - 87,5 - 108 MHz

Model page created by Danilo Crnogorac. See "Data change" for further contributors.
