• Year
  • 1960 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 72945
    • Brand: Ei

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 452/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110/220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: München - Ei, Elektronska Industrija; Ni
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 350 x 210 x 170 mm / 13.8 x 8.3 x 6.7 inch
  • Net weight (2.2 lb = 1 kg)
  • 4.2 kg / 9 lb 4 oz (9.251 lb)
  • Mentioned in
  • -- Schematic
  • Author
  • Model page created by Harald Pohlmann. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model München is part of the collections of the following members.

 Forum

Forum contributions about this model: Ei, Elektronska: München

Threads: 1 | Posts: 4

Originally producer name of this set was "Korina".

Producer gave different names for export types depending of Country where was exported, usually by city names in exported Country.
I was upload an original producer schematic diagram to the model.

Berislav Bradaric, 10.May.06
