• Country
• United States of America (USA)

• Manufacturer / Brand
• Elenco Electronics Inc., Illinois

• Year
• 1989–2011 ?

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 284003

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 1.75 inch = 4.4 cm

• Power out
• 0.5 W (undistorted)

• Material
• Printed Circuit Board

• from Radiomuseum.org
• Model: AM-FM-108 - Elenco Electronics Inc.,

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 11 x 5 x 1.75 inch / 279 x 127 x 44 mm

• Notes

• This is an educational kit and was replaced by model AM-FM-108CK in 2012.  The new model has an itegrated circuit module.



• Author
• Model page created by David Erali. See "Data change" for further contributors.
