4 Band Receiver TR4270

Elite; Kaufhof

  • Year
  • 1990 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 159004

 Technical Specifications

  • Number of Transistors
  • 4
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 4 Band Receiver TR4270 - Elite; Kaufhof
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 250 x 150 x 62 mm / 9.8 x 5.9 x 2.4 inch
  • Notes
  • 4 Band Receiver TR4270, Tonregelung, Teleskopantenne,Farbe Schwarz, IC TDA 1083.
  • Net weight (2.2 lb = 1 kg)
  • 1.8 kg / 3 lb 15.4 oz (3.965 lb)
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
